| Appollo series |
| |
Length (um) |
Width (um) |
Height (um) |
Luminous Intensity (mod) |
| min |
max |
| A10-SB |
584 |
254 |
90 |
70 |
300 |
| A15-SB |
380 |
380 |
90 |
50 |
300 |
| A24-SB |
610 |
610 |
120 |
380 |
1800 |
| |
Current (mA) |
WLD (nm) |
Forward Voltage (V) |
| min |
max |
min |
max |
| A10-SB |
20 |
445 |
465 |
2.8 |
3.6 |
| A15-SB |
20 |
445 |
480 |
2.8 |
3.6 |
| A24-SB |
120 |
445 |
480 |
2.9 |
3.8 |
|
|
| |
| Standard series |
| |
Length (um) |
Width (um) |
Height (um) |
Luminous Intensity (mod) |
| min |
max |
| 203-SB |
330 |
305 |
90 |
20 |
90 |
| 203-SB-H |
330 |
305 |
90 |
60 |
260 |
| A24-SB |
330 |
305 |
90 |
70 |
350 |
| |
Current (mA) |
WLD (nm) |
Forward Voltage (V) |
| min |
max |
min |
max |
| 203-SB |
20 |
450 |
480 |
2.8 |
3.6 |
| 203-SB-H |
20 |
445 |
475 |
3.0 |
3.6 |
| A24-SB |
20 |
510 |
540 |
2.8 |
3.6 |
|
|
| |
| Standard series |
| |
Length
(um) |
Width
(um) |
Height
(um) |
Luminous Intensity (mod) |
| min |
max |
| 203-SB-5mA |
330 |
305 |
90 |
5 |
40 |
| 205-SB-5mA |
300 |
200 |
90 |
5 |
40 |
| 207-SB-5mA |
254 |
200 |
80 |
5 |
40 |
| |
Current
(mA) |
WLD (nm) |
Forward Voltage (V) |
| min |
max |
min |
max |
| 203-SB-5mA |
5 |
450 |
480 |
2.7 |
3.2 |
| 205-SB-5mA |
5 |
460 |
480 |
2.7 |
3.2 |
| 207-SB-5mA |
5 |
460 |
480 |
2.7 |
3.2 |
|
|
